Specification :
LIGHT SOURCE
LED : 400W White LED engine
Life Span: 50000Hrs
Color temperature: 8500K
OPTICAL SYSTEM
Lens :High precision Lens
Zoom range: Beam Mode : 4°~8° Spot Mode : 4°~35° Wash Mode : 8°~60°
POWER
Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 550W
PHOTOMETRIC DATA
Lumen: 80000 lm@4m
COLOR SYSTEM
Color Wheel : 12 colors + white light with color half-color function
Color mixing system: Linear CMY+CTO
GOBO SYSTEM
Static Gobo wheel: 12 gobos + open
Rotate Gobo wheel: 7 rotating, each glass pattern can be independently forward and reverse
PRISM SYSTEM
Prism : standard single 6-row prism and 8+8 prism, each prism can be independently forward and reverse
FOCUSING SYSTEM
Linear adjustment from 4 meters to 50 meters
ATOMIZATION SYSTEM
1 independent atomization effect, soft and natural light spot
CONTROL
Control Mode: RDM, DMX512, master-slave, sound activated or auto operation,
DMX Channels: 22+26CHS
PHYSICAL
Display: LCD display, key + touch dual operation mode
Protect Rate: IP20
Housing : Flame-retardant thermoplastic
Color :Black
Pan :540°
Pan resolution :16bit
Tilt :270°
Tilt :resolution :16bit
PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.
Dimmer: 0-100%
Strobe: Variable strobe effect
Focus: motorized focus
Frost: electronic frost
DATA
Power :PowerCon connection in & out
DMX : 3pin or 5pin in & out
WEIGHT & DIMENSION
Weight: 22.5 kg
Dimension: 380*270*650mm
